Performance Measures of Tele-Protection System Based on Networked Microwave Radio Link

Full Text (PDF, 416KB), PP.21-28

Views: 0 Downloads: 0


Jitendra Singh 1,2,* Rabins Porwal 3 S.P.Singh 4

1. Department of Computer Science and Engineering, SRM University, Delhi NCR Campus, India

2. NIMS University, Jaipur, Rajasthan, India

3. Department of IT, ITS, Mohan Nagar, Ghaziabad

4. Department of Computer Science and Engineering NIMS University, Jaipur, Rajasthan, India

* Corresponding author.


Received: 21 May 2013 / Revised: 16 Oct. 2013 / Accepted: 17 Jan. 2014 / Published: 8 Apr. 2014

Index Terms

Reliability, MTTF, Tele-Protection system


The purpose of paper is to compute reliability of Digital Tele-Protection System employing Digital Microwave Radio Link. In this paper, the whole Tele-Protection system is divided into six subsystems. The first subsystem is digital relaying equipment. Second subsystem is the tale-protection signaling equipment where the timing to sample line power currents is synchronized. Both relaying and Tele-Protection signaling equipments, are now assemble three-phase current data, sampled at 600 Hz for 50 Hz EHV systems and some control data into a 90 bit frame format at a transmission rate of 54 Kb/s. A frame consists of a frame synchronization field and some information fields including a cycle’s redundancy check field. The third subsystem, Tele-Protection signed multiplexing equipment generates a super frame by multiplexing the seven, 54 Kb/s Tele-Protection signals into a 1.544 Mb/s stage using multi-point sampling technique to minimize the delay time variation and send them to the subsystem four, which is radio equipment, from here the data is transmitted with the help of the channel (subsystem 5) to the repeater station (subsystem 6). The subsystem six is used to remove the noise and to improve the power of the data. In this paper, we have taken standby digital relaying equipment and that can be online through an imperfect switching device. Also parallel redundant Tele-Protection signaling equipment is taken to improve system’s overall performance.

Cite This Paper

Jitendra Singh, Rabins Porwal, S.P.Singh, "Performance Measures of Tele-Protection System Based on Networked Microwave Radio Link", International Journal of Computer Network and Information Security(IJCNIS), vol.6, no.5, pp.21-28, 2014. DOI:10.5815/ijcnis.2014.05.03


[1]Agnihotri, R.R., Satsangi, S. K., Two Non-identical Unit System with Priority Based Repair and Inspection, Microelectronic Reliab. , Vol. 36 (2), pp 279 – 282, 1996.
[2]Cassady, C.R., Lyoob, I.M., Schneider, K., Pohi, E. A., A Generic Model of Equipment Availability under Imperfect Maintenance, IEEE TR on Reliability, Vol.54, issue - 4, pp 564 – 571, 2005.
[3]Chung, W. K., A k-out -of n, G Redundant System with the Presence of Chance with Multiple Critical Errors, Microelectronic Reliab. , Vol. 33, pp 334-338, 1993.
[4]Cluzeau, T., Keller, J., Schneeweiss, W., An Efficient Algorithm for Computing the Reliability of Consecutive-k-out-of-n:F Systems, IEEE TR. on Reliability, Vol.57 (1), pp 84-87, 2008.
[5]Dhillon, B. S. and Yang N. J.: Stochastic Analysis of Standby System with Common Cause Failure and Human Error, Microelectronic Reliab. , Vol. 32, pp 1699 – 1712, 1992.
[6]Dhillon, B. S., Reliability Analysis of Non-Maintained Parallel System Subject to Hardware Failure and Human Error, Microelectronic Reliab. Vol. 25, pp 121 -122, 1985.
[7]Fang - Ming, S., Xuemin, S., Pin - Han, H., Reliability Optimization of Distributed Access Networks with Constrained Total Cost, IEEE TR on Reliability, Vol.54, issue - 3, pp 421 – 430, 2005.
[8]Gutierrez, P.H., Aguirre, T. V., Christen, J. A., A Practical Method for Obtaining Prior Distributions in Reliability, IEEE TR. on Reliability, Vol. 54, issue - 2, pp 262 – 269, 2005.
[9]Kijima, M., Markov Processes for Stochastic Modeling, CRC Press, 1997.
[10]Lindsey, J.K., Statistical Analysis of Stochastic Processes in Time, Cambridge University Press, 2004.
[11]Linkov, L.N., Asymptotic Statistical Methods for Stochastic Processes, American Mathematical Society, 2001.
[12]Nagraja, H.N., Kannan, N., Krishnan, N.B., Reliability, Springer Publication, 2004.
