Aerodynamic System Modeling based on Proper Orthogonal Decomposition

Full Text (PDF, 794KB), PP.25-31

Views: 0 Downloads: 0


Weigang Yao 1,* Min Xu 1 Xiaojuan Wang 1

1. Northwestern Polytechnical University, Xi’an, CHINA

* Corresponding author.


Received: 25 Jan. 2011 / Revised: 4 May 2011 / Accepted: 13 Jul. 2011 / Published: 8 Nov. 2011

Index Terms

Proper Orthogonal Decomposition (POD), Inverse Design, Aeroelastic, Active Control


The main goal of present paper is to construct an efficient reduced order model (ROM) for aerodynamic system modeling. Proper Orthogonal Decomposition (POD) is presented to address the problem. First, the snapshots are collected to form the POD kernel, and then Singular Values Decomposition (SVD) is used to obtain POD modes, finally POD-ROM can be constructed by projecting full order aerodynamic system to POD modes subspace. Two problems are addressed: (1) aerodynamic data inverse design; (2) aeroelastic structure active control. For the second problem, POD method with balanced modification is introduced to improve the robustness of original POD method. Results in problem (1) suggest POD method works efficiently not only for interpolation inverse design but also for extrapolation problems. The results in problem (2) demonstrate POD method with balanced modification is efficient and accurate enough for aeroelastic system analysis.

Cite This Paper

Weigang Yao, Min Xu, Xiaojuan Wang, "Aerodynamic System Modeling based on Proper Orthogonal Decomposition", International Journal of Information Technology and Computer Science(IJITCS), vol.3, no.5, pp.25-31, 2011. DOI:10.5815/ijitcs.2011.05.04


[1]Rosenfeld A, Kark A C. Digital Picture Processing [M]. Academic Press, 1982.

[2]Algazi V R, Sakrison D J. On the optimality of the Karhunen Loéve expansion [J]. IEEE Trans. Inform. Theory, 1969, 15:319-321.

[3]Andrews C A,Davies J M,Schwartz G R. Adaptive Data Compression [J]. In Proc.IEEE,1967,55:267-277.

[4]Krysl P,Lall S,Marsden J E. Dimensional Model Reduction in Nonlinear Finite element dynamics of solids and structures [J]. International Journal for Numerical Methods in Engineering,2001,51:479-504.

[5]Lumley J L. The Structure of Inhomogeneous turbulence [J]. Atmospheric Turbulence and Wave Propagations,1967,pp.166-178.

[6]Pablo Hidalgo. POD Study of the Coherent Structures with a Turbulent Spot [J]. AIAA 2006-1099, 2006.

[7]Zhenkun Feng. Investigations of Nonlinear Aeroelasticity Using a Reduced Order Fluid Model Based on POD method [J]. AIAA 2007-4305, 2007.

[8]K.L.Lai, K.S.Won. Flutter Simulation and Prediction with CFD-based Reduced-Order Model [J]. AIAA 2006-2026, 2006.

[9]Grigorios Dimitriadis, Gareth A. Vio. Flight-Regime Dependent Reduced Order Models of CFD/FE aeroelastic systems in transonic flow [J]. AIAA 2007-1989, 2007.

[10]Piergionvanni Marzocca, Walter A. Silva, Liviu Librescu, Open/Closed-Loop Nonlinear Aeroelasticity for Airfoils via Volterra Series Approach. AIAA-2002-1484

[11]Sorin Munteanu, John Rajadas, A Volterra Kernel Reduced-Order Model Approach for Nonlinear Aeroelastic Analysis, AIAA 2005-1854

[12]Jeffrey P. Thomas, Earl H. Dowell, Virtual Aeroelastic Flight Testing for the F-16 Fighter with Stores, AIAA 2007-1640

[13]Jeffrey P. Thomas, Kennth C. Hall, Early H. Dowell, Modeling Limit Cycle Oscillation Behavior of the F-16 Fighter Using a Harmonic Balance Approach, AIAA 2004-1696

[14]Li Jie, Huang Shouzhi, Jiang Shengju, Li Fengwei, Unsteady Viscous Flow Simulation by a Fully Implicit Method with Deforming Grid. AIAA 2005-1221

[15]Moore B C. Principle Component Analysis in Linear System Controllability, Observability, and Model Reduction, IEEE Trans on Automatic Control, 1981, 26(1): 17-31

[16]Yao Weigang, Xu Min, Ye Mao. Unsteady Aerodynamic Force Modeling via Proper Orthogonal Decompostion, Chinese Journal of Theoretical and Applied Mechanics[J].42(4):638-644
