Compressive Strength Prediction of Silica Fume mixed Concrete Soaked in Used Engine Oil with a Mathematical Model

Full Text (PDF, 465KB), PP.64-76

Views: 0 Downloads: 0


Nandini M. Naik 1,* Arpa Mukherjee 2 Avik Khamaru 3 Siddhartha Ojha 3 Girish S. Kulkarni 4 K. B. Prakash 5

1. K.L.E Dr. M. S Sheshgiri College of Engineering & Technology, Belgaum, India

2. Cognizant Technology Solutions, India

3. Tata Consultancy Services Ltd, India

4. Shivaji University Kolhapur, Maharashtra, India

5. Government Engineering College Haveri, Karnataka, India

* Corresponding author.


Received: 11 Jun. 2018 / Revised: 14 Aug. 2018 / Accepted: 7 Oct. 2018 / Published: 8 Jan. 2019

Index Terms

Concrete, silica fumes, compressive strength, used engine oil, mathematical model


The determination of strength properties i.e., compressive strength (CS) is essential to estimate the load at which the concrete members may crack especially in aggressive environment. The paper reports an experimental investigation on deterioration of used engine oil (UEO) soaked concrete with respect to its strength properties. Also, it is found that this deteriorating effect is lessened with partial replacement of silica fumes (SF). The CS analysis was done with a water-concrete ratio of 0.49 with nine percentage replacements of SF (0, 5, 10, 15, 20, 25, 30, 35, 40 and 45) with water curing and UEO soaking. The soaking in two different liquids was essential in order to throw light on the detrimental effects of UEO on the CS of concrete. The results of the experiments showed that 20% replacement of SF in concrete was optimum to attain maximum CS. A mathematical model based on Abrams’ law has been developed to evaluate the strength characteristics of concrete subjected to UEO soaking. The developed model facilitates the prediction of CS based on curing time in water and soaking time in UEO and also the quantity of SF used. The accuracy of the developed model is evaluated and good agreements with the ground truth values are found.

Cite This Paper

Nandini M. Naik, Arpa Mukherjee, Avik Khamaru, Siddhartha Ojha, Girish S. Kulkarni, K. B. Prakash,"Compressive Strength Prediction of Silica Fume mixed Concrete Soaked in Used Engine Oil with a Mathematical Model", International Journal of Engineering and Manufacturing(IJEM), Vol.9, No.1, pp.64-76, 2019. DOI: 10.5815/ijem.2019.01.06


[1] Nuruddin M.F.,et al(2008). Effect of Used Engine Oil on MIHRA Concrete, A New Material In The Construction Industry. United Kingdom Malaysia Engineering Conference, vol. 28, No. 3, pp. 398-11.

[2] Wasiu O. Ajagbe, Olusola S. Omokehinde, Gabriel A. Alade, Oluwole A. Agbede, (2012). Effect of Crude Oil Impacted Sand on compressive strength of concrete. Construction and Building Materials 26 (2012) 9–12, Elsevier. doi: 10.1016/j.conbuildmat.2011.06.028

[3] M.A. Matti, (1983). Effect of oil soaking on the dynamic modulus of concrete. International Journal of Cement Composites and Lightweight Concrete, Volume 5, Issue 4, Pages 277–282, Elsevier. doi:10.1016/0262-5075(83)90069-6

[4] T.Z. Blaszczynski, ‘Concrete in contact with crude oil’, STATYBA-CIVIL ENGINEERING, No. 2(6), 1996, pp.13-17.

[5] Bhanja, S., & Sengupta, B. (2005). Influence of silica fume on the tensile strength of concrete. Cement and Concrete Research, 35(2005), 743–747.

[6] Biswal, K. C., & Sadang, S. C. (2010). Effect of superplasticizer and silica fume on properties of concrete. In Proceedings of International Conference on Advances in Civil Engineering.

[7] Katkhuda, H., Hanayneh, B., & Shatarat, N. (2009). Influence of silica fume on high strength of light weight concrete. World Academy of Science, Engineering and Technology, 58, 781–788.

[8] Popovics, S. (1998). Strength and related properties of concrete a quantitative approach. New York, NY: Wiley.

[9] Naik, Nandini M., Girish S. Kulkarni, and K. B. Prakash. "Assessment of the Deterioration of used Engine Oil Soaked Fly ash Concrete and its Analysis using Automated SEM Analysis." (2016). I.J. Engineering and Manufacturing. MECS Publishers. DOI: 10.5815/ijem.2016.03.01.

[10] Girish, S. K., K. B. Prakash, and M. N. Nandini. "Negative impact of diesel and used engine oil soaking on the compressive strength of concrete." International journal of advance research in sciences and engineering 3 (2014): 01.

[11] Naik, Nandini M., Girish S. Kulkarni, and K. B. Prakash. "Effect of solid wastes on the characteristics behaviour of petroleum products soaked concrete–A Review." (2013).

[12] Abdul Ahad, Ramzi B., and Azad A. Mohammed. "Compressive and tensile strength of concrete loaded and soaked in crude oil." (2000).

[13] Faiyadh, F. I. "Bond characteristics of oil saturated concrete." International Journal of Cement Composites and Lightweight Concrete 7.2 (1985): 115-131.

[14] Diab, Hesham. "Compressive strength performance of low-and high-strength concrete soaked in mineral oil." Construction and Building Materials 33 (2012): 25-31.

[15] Svintsov, A. P., T. SF Gamal, and E. E. Shumilin. "Effect of mineral and vegetable oil on deformation properties of concrete." RUDN Journal of Engineering Researches 18.2 (2017): 245-253.

[16] Naik, Nandini M., Girish S. Kulkarni, and K. B. Prakash. "Analysis and Treatment of Water Contaminated by Petroleum Products." (2014). MECS Publishers.
